DIAMOND ULTRAHARD GRINDING HEAD
|
SPECIFICATION DRMLS/DRMLSX- Outer Diameter* Thickness*Bore Diameter (mm)
|
||
|---|---|---|
|
Model Ⅰ
|
Model ⅠⅠ
|
|
|
Model ⅠⅠⅠ
|
Model Ⅳ
|
|
|
Specification【DRMTⅠ/Ⅱ/Ⅲ/Ⅳ-D1*L1MD2*(L-L1)(mm)】
|
Remarks
|
||
|---|---|---|---|
|
DRMTⅠ/Ⅱ/Ⅲ-07*20M06*40
|
DRMTⅠ/Ⅱ/Ⅲ-09*20M06*40
|
Customization accepted as per request regarding Diamond mesh No. /length and external diameter≦20mm.
|
|
|
DRMTⅠ/Ⅱ/Ⅲ-12*36M06*30
|
DRMTⅠ/Ⅱ/Ⅲ-15*36M06*30
|
||
|
DRMTⅠ/Ⅱ/Ⅲ-17*36M06*30
|
DRMT Ⅳ-17*35M06*33
|
||
|
DRMTⅠ/Ⅱ/Ⅲ-19*36M06*30
|
DRMT Ⅳ-19*35M06*33
|
||
|
AIR DIE GRINDER (ADGⅠ-220)
|
||
|---|---|---|
|
1. Install end grinds of 10mm or 6mm shank diameter.
2. Maximum speed: 22,000 RPM 3. Air pressure: 0.7-0.8 MPa 4. A 3HP power air compressor for only one air die grinder. 5. A screw air compressor for multiple air die grinders at the same time.
|
||
|
FOR AUTOMATIC EQUIPMENT
|
||
|---|---|---|
|
Remarks: Customized products can be designed and manufactured for automatic grinding equipment as per request from the customer.
|
||
|
Application: Manually & automatically grind the curved surface, groove and bore of cast iron.
|
||
